    Section Bending Machine

    Experienced and actual users, keeping in mind most rigorous working environment, designed our machine with extensive calculations of stresses and loads on every component. This has created a robust machine with adequate safety factors and with minimum power requirement. It saves upon the electricity consumption, thus effective running cost.

    All components are suitably machined to provide true alignment, which gives a better-finished product. True alignment also enhances the longevity of the machine eliminating breakdown and revenue loss.

    Use of Helical gears, which has better load bearing capacity as compared to Spur Gear, which enhances the longevity of the machine eliminating breakdown and revenue loss.

    Machine is equipped with dynamically designed support roll system, which arrests the skewing of the machine, which again increases the longevity of the machine eliminating breakdown and revenue loss with a better finished product.

    Only maintenance required is oiling at various points.
    Along with our machine we provide the following test and guarantee certificates

    1. Test certificates for the material used.
    2. Ultrasonic test certificate for the forgings used.
    3. Guarantee and test certificate for the motor used.
    4. Guarantee and test certificate for the Gear Box used.
    5. 12 months warranty for our product

    PRICE: ON REQUEST

    Get Quotation
    Download Brochure
    Request Callback

    Order by Phone
    0671-2505250

    Shipping Information Usually dispatched With In business days.

    Technical Specifications

    Description Model
    HM-25 HB-40 HBH-40 HB-50 HBH-50 HBD-50 HBD-85 HBD-120 HBD-150
    Pipe 25 x 2 35 x 3 35 x 3 45 x 4 45 x 4 45 x 4 75 x 6 100 x 6 140 x 5
    Round Tube 32 x 1 40 x 2 40 x 2 50 x 2 50 x 2 50 x 2 85 x 3 120 x 3 160 x 3
    Square Tube 30 x 1 35 x 2 35 x 2 40 x 2 40 x 2 40 x 2 70 x 3 90 x 5 100 x 5
    Angle Iron 30 x 3 35 x 5 35 x 5 45 x 6 45 x 6 45 x 6 85 x 6 100 x 10 120 x 6
    Solid Round 22 32 32 35 35 35 60 70 80
    Solid Square 19 28 28 35 35 35 50 60 70
    Flat Bar 50 x 6 50 x 10 50 x 10 60 x 10 60 x 10 60 x 10 80 x 20 100 x 20 100 x 25
    T Shape Angle 30 x 3 35 x 5 35 x 5 45 x 6 45 x 6 45 x 6 85 x 6 100 x 10 120 x 6
    C Channel 20 x 10 40 x 20 40 x 20 60 x 30 60 x 30 60 x 30 80 x 45 100 x 50 125 x 65
    Upper Roll Dia. 100 130 130 150 150 180 250 315 390
    Lower Roll Dia. 115 130 130 150 150 180 250 315 390
    Roll Adjustment Manual Manual Hydraulic Manual Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic
    Pinch Single Single Single Single Single Double Double Double Double
    Driven Rolls Two Two Two Two Two Two Two Three Three
    Speed RPM N.A. 15 15 15 12 11 5 5 3
    Power HP N.A. 2 2 3 3 3 5 10 15
    Weight Kgs. 210 370 460 580 690 930 1620 2250 4550
    OPTIONAL ACCESSORIES STANDARD ACCESSORIES APPLICATIONS
    1. OPTIONAL ROLLS DEPENDING UPON THE 1. SM Series : One Set of Roll Tool, Screw Operating Rod, Handle, Nut Spanner & Storage Cabinet. 1. ELECTRIC PANNELS
    2. CROSS SECTION TO BE BEND 2. SB Series : One Set of Roll Tool, Gear Box, Electric Motor, Control Panel, Screw Operating Rod & Nut Spanner. 2. ROOFINGS
    3. SBH Series : One Set of Roll Tool, Gear Box, Hydraulic Unit, Electric Motors, Pressure Gauge, Control Panel, Screw Operating Rod & Nut Spanner. 3. BUS BODIES
    4. SBD Series : One Set of Roll Tool, Gear Box, Hydraulic Unit, Electric Motors, Pressure Gauge, Control Panel, Screw Operating Rod & Nut Spanner.. 4. KITCHEN EQUIPMENTS
    5. GENERATOR ENCLOSURES
    6. & Motor Pulley
    7. STAINLESS STEEL EQUIPMENT’S
    8. COIL CUTTING INDUSTRIES
    9. AIR CONDITION DUCTS
    10. CONTAINER MANUFACTURING
    11. FLOUR MAKING MACHINES
    12. INDUSTRIAL STRUCTURES
    13. RAIL COACHES
    14. TIPPER TRUCKS
    15. WIND MILL MANUFACTURING
    16. TURNINE ENCLOSURES
