    Hydraulic Shearing Machine

    Squaring arm 1000mm at left with hardened lines.
    Squaring arm 600mm at right helps distribute wear.
    Front gauging with stops, scale on squaring arm.
    Hardened rods recessed table for easy sheet feeding.
    Sheet supports 1000mm help supports long plates.
    Ramp on rear slides cut out sheet outside shear area.
    Foot switch movable for operation from self position.
    Finger safety guard with clear view of lighted cutting area.
    Efficient compact power pack minimum piping.
    Electrical neatly wired-cabled for trouble shooting.

    PRICE: ON REQUEST

    Get Quotation
    Download Brochure
    Request Callback

    Order by Phone
    0671-2505250

    Shipping Information Usually dispatched With In business days.

    Technical Specifications

    Model Shearing Length
    mm    		 Shear Thic. Rake Angle/(Min./Max.) Rake Angle Rake Angle Range Strokes/Minute at Min. & Max.
    Rake Angle    		 Holddowns Holding Force kgs. Power H.P. Over all Diamensions
    in mm
    (L x W x H )    		 Approx.
    Weight
    Kgs.
    LHVR325 2500 3.15 / 4 2 / 3 1’15” 0.5-2” 28-13 13 2500 5 3150 x 2000 x 2400 3800
    LHVR330 3000 3.15 / 4 2 / 3 1’15” 0.5-2” 24-9 16 2500 5 3500 x 2000 x 2400 4400
    LHVR412 1250 4 / 6 3 / 4 1’37” 0.5-3“ 33-17 5 4000 5 2000 x 2000 x 2400 2700
    LHVR415 1500 4 / 6 3 / 4 1’37” 0.5-3“ 30-15 8 4500 5 2250 x 2000 x 2400 3200
    LHVR420 2000 4 / 6 3 / 4 1’37” 0.5-3“ 28-13 11 6200 7.5 2750 x 2000 x 2400 3500
    LHVR425 2500 4 / 6 3 / 4 1’37” 0.5-3“ 26-8 13 8000 7.5 3400 x 2350 x 2450 5200
    LHVR430 3000 4 / 6 3 / 4 1’37” 0.5-3“ 24-6 16 10000 10 4000 x 2350 x 2450 6000
    LHVR440 4000 4 / 6 3 / 4 1’45” 0.5-3“ 22-6 20 12000 10 4500 x 2350 x 2450 8500
    LHVR615 1500 6 / 8 4 / 6 1’45” 0.5-3“ 24-8 9 6600 10 2250 x 2350 x 2500 4000
    LHVR620 2000 6 / 8 4 / 6 1’45” 0.5-3“ 22-7 11 6500 10 2750 x 2350 x 2500 4300
    LHVR625 2500 6 / 8 4 / 6 1’45” 0.5-3“ 28-8 14 8500 15 3400 x 2350 x 2500 6200
    LHVR630 3000 6 / 8 4 / 6 1’45” 0.5-3“ 24-6 16 10800 15 4000 x 2200 x 2500 7000
    LHVR640 4000 6 / 8 4 / 6 2” 0.5-3“ 24-6 20 13600 20 5100 x 2700 x 2800 8400
    LHVR815 1500 8 / 10 6 / 8 2” 0.5-3“ 22-10 9 10500 15 2250 x 2600 x 2650 5000
    LHVR820 2000 8 / 10 6 / 8 2” 0.5-3“ 18-8 11 12500 15 2750 x 2600 x 2650 5500
    LHVR825 2500 8 / 10 6 / 8 2” 0.5-3“ 24-8 14 16300 20 3500 x 2600 x 2650 6800
    LHVR830 3000 8 / 10 6 / 8 2” 0.5-3“ 20-6 16 18500 20 4200 x 2600 x 2650 7700
    LHVR840 4000 8 / 10 6 / 8 2” 0.5-3“ 20-8 20 23000 25 5200 x 2900 x 2800 13500
    LHVR1015 1500 10 / 13 8 / 10 2” 0.5-3“ 20-10 9 10500 15 2250 x 2650 x 2700 5500
    LHVR1020 2000 10 / 13 8 / 10 2” 0.5-3“ 18-8 11 12600 15 2750 x 2650 x 2700 6000
    LHVR1025 2500 10 / 13 8 / 10 2” 0.5-3“ 24-8 14 17500 20 3600 x 2650 x 2700 8000
    LHVR1030 3000 10 / 13 8 / 10 2” 0.5-3“ 20-6 16 20000 20 4200 x 2650 x 2700 10500
    LHVR1040 4000 10 / 13 8 / 10 2” 0.5-3“ 18-6 20 25000 30 5200 x 2900 x 2900 15200
    LHVR1320 2000 13 / 16 10 / 13 2” 1-3” 13-5 11 16500 20 2750 x 2650 x 2950 7000
    LHVR1325 2500 13 / 16 10 / 13 2” 1-3” 15-10 13 32000 25 3600 x 2650 x 2950 9600
    LHVR1330 3000 13 / 16 10 / 13 2” 1-3” 12-6 16 37000 25 4200 x 2650 x 2950 11800
    LHVR1340 4000 13 / 16 10 / 13 2” 1-3” 10-4 20 22000 30 5200 x 3000 x 3050 17800
    LHVR1620 2000 16 / 20 13 / 16 2” 1-3” 13-7 11 20000 25 2750 x 2950 x 3150 12000
    LHVR1625 2500 16 / 20 13 / 16 2” 1-3” 15-8 13 40000 30 3600 x 2950 x 3150 12000
    LHVR1630 3000 16 / 20 13 / 16 2” 1-3” 12-6 16 43500 30 4250 x 2950 x 3150 15300
    LHVR1640 4000 16 / 20 13 / 16 2” 1-3” 10-4 20 30000 30 5200 x 3050 x 3500 21500
    LHVR2020 2000 20 / 25 16 / 20 2” 1-3” 16-8 11 32000 40 2900 x 2950 x 3150 17000
    LHVR2025 2500 20 / 25 16 / 20 2” 1-3” 15-8 13 48000 40 3600 x 2950 x 3150 18000
    LHVR2030 3000 20 / 25 16 / 20 2” 1-3” 12-6 16 52000 40 4250 x 2950 x 3150 20000
    LHVR2040 4000 20 / 25 16 / 20 2” 1-3” 10-4 20 30000 50 5200 x 3050 x 3500 24000
    OPTIONAL ACCESSORIES STANDARD ACCESSORIES APPLICATIONS
    1. Sheet front feeding system. 1. Moving beams synchronized by differential cylinders. 1. ELECTRIC PANNELS
    2. NC background with ball screw. 2. Shearing-clamping forces adjustable to suit jobs. 2. ROOFINGS
    3. Hydraulic rear sheet support. 3. Both Blades premium HCHCR, with four useable edges. 3. BUS BODIES
    4. Automatic control shearing. 4. Cutting lengths and positions adjustable for shorter jobs. 4. KITCHEN EQUIPMENTS
    5. Sheet rear stacking system. 5. Beam returns on releasing foot switch smaller cut. 5. GENERATOR ENCLOSURES
    6. Motorize back gauge 6. Cutting area illuminated for clear view of blades. 6. STEEL TANKS
    7. Self lubrication 7. First two hold downs spaced closer at both ends 7. STAINLESS STEEL EQUIPMENT’S
    8. Motor mounting bracket 8. COIL CUTTING INDUSTRIES
    9. Motor pulley 9. AIR CONDITION DUCTS
    10. V belts 10. CONTAINER MANUFACTURING
    11. FLOUR MAKING MACHINES
    12. INDUSTRIAL STRUCTURES
    13. RAIL COACHES
    14. TIPPER TRUCKS
    15. WIND MILL MANUFACTURING
    16. TURNINE ENCLOSURES
